Why Choose Our Flexible Storage Tanks?
1) Global Certification: Our tanks meet international standards including FDA (food grade) and ISO 9001, ensuring they meet your highest quality requirements.
2) One-Stop Service: We provide comprehensive support from design customization to transportation guidance, offering full technical support throughout the process.
3) Industry Proven: We have extensive experience serving over 500 customers worldwide, covering agriculture, logistics, and rescue sectors, and are committed to providing reliable solutions that meet your needs.
Core Advantages:
- Excellent Material Performance Premium TPU composite material features outstanding oil-resistance, abrasion-resistance, anti-aging and UV-resistance. Stable performance under wide temperature range -40℃ ~ +80℃; anti-static version is optional for flammable-liquid working conditions.
2.Foldable & Portable Can be fully folded after emptying, greatly reduce occupied space for storage and logistics, convenient for remote-area deployment. No heavy metal frame required.
3.Reliable Leak-proof Structure High-frequency welded seams with reinforced stress-points. Multiple optional stainless-steel ports, flanges and quick-coupling fittings to meet different filling-discharging requirements. Every unit passes air-tightness pressure test before delivery.
4.Highly Customizable Support custom capacity, shape, color, valve configuration and LOGO printing. Thickness options: 0.7 mm / 0.9 mm / 1.2 mm according to customer working conditions.
Application Scenarios:
- Mining & Construction Sites: Temporary diesel / fuel storage for heavy-duty machinery in remote working sites.
- Marine & Off shore: Auxiliary fuel storage for ships, yachts and offshore engineering equipment.
- Field Engineering & Emergency Reserve: Outdoor mobile fuel supply, disaster-response emergency liquid storage.
- Industrial Field: Storage of lubricants, hydraulic oil and various non-hazardous industrial liquids.
Technical Specifications
| Item | Parameter |
| Material | TPU coated polyester fabric |
| Thickness | 0.7 mm / 0.9 mm / 1.2 mm (customizable) |
| Capacity Range | 50L-200,000L customized |
| Working Temperature | -40℃ ~ +80℃ |
| Working Pressure | Normal low-pressure ≤0.5 bar |
| Shape | Pillow-type / square / customized shape |
| Fittings | Inlet & outlet valves, flange joints, quick couplings, lifting Drings (optional) |
| Feature | Reusable, foldable, UV-resistant, leak-proof; anti-static option available |
| Color | Army green, blue, black, custom colors acceptable |
| Testing | Air-tightness pressure test for each finished unit |
